Insulated Steel 600 Series - Rock River Door

Make a Statement.

Insulated Steel 600 Series

The 600 Series combines the look of deep embossed wood grain with the strength and durability of heavy gauge galvanized steel to provide years of virtually maintenance free use. No worries about warping, cracking or rotting. Backed by a Limited Lifetime Warranty, the Insulated Steel 600 Series is ideal for all climates. It’s the easy way to add beauty and value to your home.

600 SERIES MODELS

Flush Panel

V-Groove Panel

Ribbed Short Panel

Recessed Short Panel

Ribbed Long Panel

Recessed Long Panel

Raised Ranch Panel

Raised Standard Panel

Raised Sculptured Panel

WOOD GRAIN COLORS

The pre-painted wood grain finish is baked on to ensure a durable and long lasting door.

PLANK WOOD GRAINS

With plank designs the length of the door section, each door has a varied section stack, adding another interesting level to the overall appearance. The versatility of the plank complements both modern homes and traditional styles, making them unique and bold

Cedar Plank

English Oak Plank

American Walnut Plank

BI-DIRECTIONAL WOOD GRAINS

A vertical wood grain pattern on the panel and stile contrasting with a horizontal pattern on the rails creates the appearance of a real wood door.

Ash

English Oak

American Walnut

Mahogany

UNI-DIRECTIONAL WOOD GRAINS

These authentic colors feature a woodgrain pattern that runs horizontally to complement any of our insulated steel models.

Ash

English Oak

American Walnut

Mahogany

Graywood

DECORATIVE GLASS OPTIONS

Clear/Clear

Clear/Frosted

INSULATED GLASS OPTIONS

Clear/Clear

Light Gray/Clear

Dark Gray/Clear

Clear/Frosted

Light Gray/Frosted

Dark Gray/Frosted

Bronze/Clear

Clear/Low-E

Dark Gray/Dark Gray

Bronze/Frosted

Clear/Solar Shield

Obscure/Clear

Obscure/Frosted

*Translucent Mirror (Dark in Garage)

Translucent Mirror (Light in Garage)

NON-INSULATED GLASS OPTIONS

Clear

Light Gray

Dark Gray

Frosted

Bronze

Clear Lexan

Obscure

TECHNICAL INFORMATION

The 600 Series is available with Decorative Glass options. Three decorative designs. Insulated tempered 1/2" glass with design on third surface. Opacity levels ranging from clear to moderately opaque. Available for Carriage House, Ranch and Standard Series windows

The 600 Series provides maximum energy efficiency by using environmentally compliant polyurethane foam insulation. This means a 0.106 Tested U-Factor. The result is a garage door with more than 5 times the insulating value of wood or non-insulated doors.

600 Series doors are 1-3/8" thick. A full thermal break is used in the tongue-and-groove construction of all 600 series doors. These rigid vinyl top and bottom caps seal the joints and minimizes metal-to-metal contact, which limits the transfer of temperature. 600 series doors exceed the ASHRAE 90.1 standard when installed with standard bottom seal and commonly available vinyl door stop.

All 600 Series doors include a three-tier corrosion-resistant protective finish with a polyurethane primer and a durable polyester finish coat on the interior and exterior. Haas Door's paint thickness is one of the highest in the industry.

The 600 Series is also available in a wide range of design pressures for wind load requirements. Contact your local Haas Door dealer for more information about wind load requirements in your area.

Exterior & interior skins are made of galvanized steel to assure protection from warping, rotting and rusting. Heavy 20-gauge back-up plates extend the full height of each section to give superior hardware support.

A heavy bottom weather seal that flexes to fit the contour of the floor is included on all of our 600 series doors. This combination of protection seals out the elements and repels the most hostile weather conditions.

Impact polycarbonate is available in Clear with UV rating, Dark Gray, Bronze, Frosted, and Pebble. Polycarbonate requires special cleaning methods

DECORATIVE HARDWARE

Handles (standard)

Hinges (optional)
